A well-known manufacturer and supplier of nickel alloy pipe fittings with headquarters in Delhi, Heer Fittings offers high-strength, corrosion-resistant piping solutions. These fittings are designed to satisfy the needs of sectors like chemical processing, aerospace, marine, and power generation that operate in harsh environments. Heer Fittings offers a comprehensive selection of precisely manufactured nickel alloy elbows, tees, reducers, and caps that meet international standards. These fittings are renowned for their long service life and high performance, as well as their resilience to harsh chemicals. Heer Fittings provides excellent technical support, timely delivery, and tailored solutions to match client-specific needs.
| Specification : | ASTM B 366 / ASME SB 366 |
| Dimensions : | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
| Size : | Seamless 1/2″ – 10″ , Welded 1/2″ – 48″ |
| Thickness : | Sch Sch 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160 Sch XXS |
| Types : | Seamless / ERW / Welded / Fabricated |
| Nickel 200: 2.4066, N02200, NW 2200 Nickel 201: 2.4068,N02201, NW 2201 |
Up to 99% of nickel alloy pipe fittings are made of nickel; however, depending on the grade (e.g., Alloy 200, 400, 600), they may also contain chromium, molybdenum, iron, copper, and other elements. They provide exceptional resistance to corrosive environments, especially reducing acids and alkalis, good ductility, and exceptional tensile strength (up to 758 MPa). These fittings have outstanding weldability and machinability and retain mechanical stability over a broad temperature range. They are perfect for high-performance applications in demanding media and are manufactured in compliance with ASTM B366 and other international standards.
| Grade | C | Ni | Si | S | Mn | Cu | Fe |
|---|---|---|---|---|---|---|---|
| Nickel 200 | 0.15 max | 99.0 min | 0.35 max | 0.01 max | 0.35 max | 0.25 max | 0.40 max |
| Nickel 201 | 0.02 max | 99.0 min | 0.35 max | 0.01 max | 0.35 max | 0.25 max | 0.40 max |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Nickel 200 / 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Heer Fittings is a leading supplier of Nickel Alloy Pipe Fittings in Delhi, India. We offer an extensive range of Nickel Alloy Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
|---|---|---|---|---|---|---|---|
| Ni 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | НП-2 |
| Ni 201 | N02201 | 2.4068 | – | LC-Ni 99 | NW 2201 | NA 12 | НП-2 |
Nickel Alloy Pipe Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Yes, custom sizes for Nickel Alloy Pipe Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.co.in.
Industries like chemical processing, pulp and paper, power plants, and pharmaceuticals that demand exceptional corrosion resistance frequently use nickel alloy pipe fittings. These fittings are appropriate for pickling lines, reactors, and distillation towers because they are perfect for applications involving sulphuric, hydrofluoric, or hydrochloric acids. They are dependable in high-pressure and high-temperature settings due to their resistance to stress cracking and thermal expansion. Additionally, nickel alloy fittings are utilised in the production of electronics and food processing, where resistance to contamination is crucial. In mission-critical systems, their robust performance and extended service life minimise maintenance and downtime.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
