Heer Fittings, a well-respected manufacturer and supplier located in Delhi, India, specializes in a diverse array of precision-engineered Reducing Outlet Tees, tailored to meet the intricate needs of various piping systems. Renowned for their durability, precise dimensions, and top-notch finish, these tees are expertly crafted to connect a smaller pipe to a larger main pipe. Heer Fittings offers Reducing Outlet Tees in a variety of materials, sizes, and pressure ratings, making them suitable for applications in the oil and gas, petrochemical, power, and chemical industries. With cutting-edge manufacturing techniques and rigorous quality control, they guarantee reliable performance and longevity even in high-demand settings.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless 1/2″ – 10″ , Welded 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc.
Grades : Nickel 200, Nickel 201
These Reducing Outlet Tees are produced using a range of materials, such as stainless steel, carbon steel, alloy steel, and nickel alloys, depending on the specific application. The mechanical properties differ based on the material grade; for example, stainless steel types can have tensile strengths ranging from 500 to 750 MPa and yield strengths between 200 and 450 MPa. Designed to withstand high pressure and temperature variations, these tees offer exceptional corrosion resistance, impact strength, and weldability. Their precise design ensures smooth flow transitions while maintaining structural integrity, making them perfect for both standard and critical operations in piping systems.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel 200 | 0.15 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Nickel 201 | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel 200 / 201 | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
Heer Fittings is a leading supplier of Nickel Alloy Buttweld Fittings in Delhi, India. We offer an extensive range of Nickel Alloy 201 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Nickel 200 | 2.4066 | N02200 | NW 2200 | NA 11 | НП-2 | N-100M | Ni 99.2 |
| Nickel 201 | 2.4068 | N02201 | NW 2201 | NA 12 | НП-2 | – | LC-Ni 99 |
Nickel Alloy Buttweld Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel alloy buttweld fittings offer excellent corrosion resistance, especially in aggressive environments like acidic and chloride-rich conditions. Their high-temperature resistance makes them ideal for industrial applications exposed to extreme heat. These fittings also provide superior strength, ensuring durability and reliability in demanding systems. Their excellent weldability and formability make installation and maintenance easier. Nickel alloys are known for their resistance to stress corrosion cracking, pitting, and crevice corrosion, ensuring long-term performance and reducing downtime. Overall, these fittings are perfect for chemical processing, marine, and aerospace industries.
Yes, custom sizes for Nickel Alloy Buttweld Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com.
Reducing Outlet Tees are commonly utilized in piping systems where a branch connection with a smaller pipe size is necessary. Frequently found in oil and gas pipelines, chemical processing facilities, and power generation plants, these fittings enable seamless flow redirection with minimal pressure loss. In HVAC systems, water treatment facilities, and fire protection setups, they allow for the integration of smaller outlet lines from a main header. Their capacity to endure high pressures and temperatures, along with their corrosion resistance and mechanical strength, makes them ideal for both aboveground and underground installations in challenging industrial environments.
