In Delhi, India, Heer Fittings is a top manufacturer and supplier of Inconel pipe fittings, providing premium solutions to sectors that require exceptional heat and corrosion resistance. The company offers a variety of Inconel fittings, including elbows, tees, reducers, and caps, with a strong emphasis on quality, accuracy, and performance. These fittings, which are made in accordance with international standards, are appropriate for demanding settings such as chemical processing, offshore, and marine environments. Through timely service and specialised product solutions, Heer Fittings combines technical excellence with customer satisfaction to guarantee that every product satisfies exact specifications and industry standards.
| Specification | ASTM B366, ASTM SB 366, ASTM B564, ASME SB564 |
| Grade | Inconel 600 (UNS N06600, Alloy 600, 2.4816), Inconel 601 (UNS N06601, Alloy 601, 2.4851), Inconel 625 (UNS N06625, Alloy 625, 2.4856), Inconel 800 (UNS N08800, Alloy 800) |
| Type | Seamless / Welded / Fabricated |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Range | ½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Dimensions | ANSI/ASME B16.9, B16.28, MSS-SP-43. |
Nickel (up to 72%), chromium (14–17%), iron, molybdenum, and trace elements make up the majority of Inconel pipe fittings. High tensile strength (up to 965 MPa), yield strength, and remarkable oxidation resistance at high temperatures are characteristics of grades such as Inconel 600, 625, and 825. These fittings are resistant to stress corrosion, cracking, and pitting and have strong mechanical qualities over a broad temperature range. They are perfect for the most demanding industrial applications because they meet ASTM B366 standards and remain durable under high pressure and high temperature.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
Heer Fittings is a leading supplier of Inconel Pipe Fittings in Delhi, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WNR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
| Inconel 601 | 2.4851 | N06601 | NCF 601 | NA 49 | XH60BT | NC23FeA | NiCr23Fe |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Inconel 718 | 2.4668 | N07718 | – | – | – | – | – |
Inconel Pipe Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | 180 DEG RETURN BENDS | REDUCERS | ELBOWS AND TEES | 180 DEG RETURN BENDS | CAPS |
|---|---|---|---|---|---|---|---|
| NPS | ID at End (1), (3), (4) | OD at Bevel (1), (2) | Centre-to- Centre O | Overall Length H | Centre -to- End Dimension A, B, C, M | Alignment of Ends U | Overall Length E |
| ½ to 2½ | 0.003 | 0.006 -0.003 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 3 to 3 ½ | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 4 | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 5 to 8 | 0.006 | 0.009 -0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.025 |
| 10 to 18 | 0.012 | 0.016 -0.012 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 20 to 24 | 0.019 | 0.025 -0.019 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 26 to 30 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.012 | … | 0.038 |
| 32 to 48 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.019 | … |
Nominal Pipe Size | 45° Elbow | 90° Elbow | OD | 180° Returns | ||||
(inch.) | LR | SR | LR | LR | ||||
Radius (inch.) | Center to Face (inch.) | Center to Face (inch.0) | Center to Face (inch.0) | (inch) | (millimeter) | Back to face (inch.) | Center to Center (inch.) | |
1/2 | 5/8 | – | 1 1/2 | 0.0840 | 21.03 | 1 7/8 | 2 | |
3/4 | 7/16 | – | 1 1/8 | 1.0050 | 26.07 | 1 11/16 | 2 1/4 | |
1 | 7/8 | 1 | 1 1/2 | 1.0315 | 33.04 | 2 3/16 | 3 | |
1 1/4 | 1 | 1 1/4 | 1 7/8 | 1.0660 | 42.02 | 2 3/4 | 3 3/4 | |
1 1/2 | 3 | 1 1/8 | 1 1/2 | 2 1/4 | 1.0900 | 48.03 | 3 1/4 | 4 1/2 |
2 | 4 | 1 3/8 | 2 | 3 | 2.0375 | 60.03 | 4 3/16 | 6 |
2 1/2 | 5 | 1 3/4 | 2 1/2 | 3 3/4 | 2.0875 | 73.00 | 5 3/16 | 7 1/2 |
3 | 6 | 2 | 3 | 4 1/2 | 3.0500 | 88.09 | 6 1/4 | 9 |
3 1/2 | 7 | 2 1/4 | 3 1/2 | 5 1/4 | 4.0000 | 101.06 | 7 1/4 | 10 1/2 |
4 | 8 | 2 1/2 | 4 | 6 | 4.0500 | 114.03 | 8 1/4 | 12 |
5 | 10 | 3 1/8 | 5 | 7 1/2 | 5.0563 | 141.03 | 10 5/16 | 15 |
6 | 12 | 3 3/4 | 6 | 9 | 6.0625 | 168.03 | 12 5/16 | 18 |
8 | 12 | 5 | 8 | 12 | 8.0625 | 219.01 | 16 5/16 | 24 |
10 | 15 | 6 1/4 | 10 | 15 | 10.0750 | 273.01 | 20 3/8 | 30 |
12 | 18 | 7 1/2 | 12 | 18 | 12.0750 | 323.09 | 24 3/8 | 36 |
Yes, custom sizes for Inconel Pipe Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com.
Oil and gas, chemical processing, aerospace, and marine industries all use Inconel pipe fittings. They are perfect for nuclear plants, reactors, turbines, exhaust systems, and heat exchangers because of their resistance to high temperatures. These fittings withstand oxidation and corrosion well in both acidic and alkaline environments. Because of its resistance to saltwater, Inconel is widely used in offshore oil drilling operations. Inconel is crucial in highly engineered systems where durability and safety are of the utmost importance due to its strength and stability under pressure. In mission-critical applications, these characteristics guarantee dependable operation and extended service life.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
