Hastelloy Forged Fittings

Based in Delhi, India, Heer Fittings is a well-known producer and supplier of Hastelloy Forged Fittings that offers corrosion-resistant solutions for extremely demanding settings. These fittings are appropriate for high-pressure and high-temperature applications because they are forged for increased strength and durability. Heer Fittings guarantees that every component is made in accordance with ASTM and ASME standards and offers a variety of types, including elbows, tees, unions, couplings, and plugs. The company is a preferred supplier in a variety of industries, including chemical processing, power plants, marine, and pharmaceuticals, thanks to its dedication to precision engineering, timely delivery, and customer-focused service.

Werkstoff No. 2.4617 Hastelloy High Pressure Forged Fittings India, Manufacturer Of ASTM B564 C276 Hastelloy Bushing United kingdom, Hastelloy ASTM B564 B2 Cross Delhi, Hastelloy C22 Equal Tee Delhi, X Hastelloy Full Couplings India, BS 3799 Union Delhi, Alloy C4 Forged 90 Deg Screwed Threaded Elbow in India.

Hastelloy Forged Fittings Specification

Specifications	ASTM B564 & ASME SB564
Standard	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size	1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Grades	Hastelloy C276, C22, C4, C2000, B2, B3, X Forged Fittings
Type	Socketweld Fittings, Screwed-Threaded Fittings
Class	2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS

The main component of Hastelloy Forged Fittings is nickel (up to 60%), with trace elements, iron, chromium, and molybdenum (15–17%) added. These fittings have outstanding corrosion resistance, high ductility, and superior tensile strength (690 MPa). Grain structure is improved during the forging process, which raises mechanical toughness and stress resistance. Hastelloy forged fittings are made to ASTM B564 standards and are intended for demanding conditions with high levels of oxidisers, reducing agents, and temperature changes. They provide durability and dependability in harsh media by successfully fending off pitting, crevice corrosion, and stress corrosion cracking.

Hastelloy Forged Fittings Chemical Composition

Grade	C	Mn	Si	S	Co	Ni	Cr	Fe	Mo	P
C276	0.010 max	1.00 max	0.08 max	0.03 max	2.50 max	50.99 min*	14.50 – 16.50	4.00 – 7.00	15.00 – 17.00	0.04 max
C22	0.010 max	0.50 max	0.08 max	0.02 max	2.50 max	50.015 min*	20.00 – 22.50	2.00 – 6.00	12.50 – 14.50	0.02 max
B2	0.02 max	1.0 max	0.1 max	0.03 max	1.0 max	Bal	1.0 max	2.0 max	26 – 30	0.04 max

Hastelloy Forged Fittings Mechanical Properties

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Hastelloy C276	8.89 g/cm3	1370 °C (2500 °F)	Psi – 1,15,000 , MPa – 790	Psi – 52,000 , MPa – 355	40 %
Hastelloy C22	8.69 g/cm3	1399 °C (2550 °F)	Psi – 1,00,000 , MPa – 690	Psi – 45000 , MPa – 310	45 %
Hastelloy B2	9.2 g/cm3	1370 °C (2500 ºF )	Psi – 1,10,000 , MPa – 760	Psi – 51000 , MPa – 350	40 %

Hastelloy Forged Fittings Standards / Types And Pressure Class

ASME 16.11, MSS SP-79, 83, 95, 97 Forged Pipe Fittings India, Hastelloy UNS N10276 Forged Pipe Fittings United kingdom, Stockist of Alloy C22 Forged Elbow Delhi, Hastelloy C276 Forged Fittings Delhi, Hastelloy UNS N10665 Forged Fittings India, Global Supplier of Hastelloy B2 Socket weld Fittings Delhi, C2000 Hastelloy Threaded Fittings Dealer in India.

ASME SB564 Hastelloy Forged Fittings Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	GOST	EN	OR
Hastelloy C276	2.4819	N10276	NW 0276	ХН65МВУ	NiMo16Cr15W	ЭП760
Hastelloy C22	2.4602	N06022	NW 6022	–	NiCr21Mo14W	–
Hastelloy B2	2.4617	N10665	–	–	–	–

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

If You Are Looking To Buy High Quality

Why Choose Hastelloy Forged Fittings from Heer Fittings?

Hastelloy Forged Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.

Best Price of B2 Hastelloy 3000 LB Forged Screwed Fittings Exporter In India, DIN 2.4819 Hastelloy Alloy Street Elbow United kingdom, Hastelloy Alloy DIN 2.4602 Forged Steel Fittings Delhi, Stockholder Of Hastelloy UNS N06455 Threaded Plug Delhi, Hastelloy UNS N06200 Socket Weld Cap India, ASME SB564M Hastelloy C22 Class 6000 Fittings Wholesaler Delhi, C276 Hastelloy Alloy Pipe Nipple Traders in India.

Customer Support

Largest Inventory

On Time Deliveries

ISO Certified

Types of Hastelloy Forged Fittings

Are Custom Sizes Available for Hastelloy Forged Fittings?

Yes, custom sizes for Hastelloy Forged Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.co.in

ASME 16.11, MSS SP-79, 83, 95, 97 Forged Pipe Fittings India, Hastelloy UNS N10276 Forged Pipe Fittings United kingdom, Stockist of Alloy C22 Forged Elbow Delhi, Hastelloy C276 Forged Fittings Delhi, Hastelloy UNS N06200 Socket Weld Cap India, ASME SB564M Hastelloy C22 Class 6000 Fittings Wholesaler Delhi, C276 Hastelloy Alloy Pipe Nipple Traders in India.

Application Industry of Hastelloy Forged Fittings

Industries including pollution control, nuclear power, marine, and chemical processing use Hastelloy Forged Fittings. They are perfect for equipment and pipelines that are subjected to strong acids such as nitric, sulphuric, and hydrochloric acids. Reactors, distillation columns, condensers, and heat exchangers are examples of common applications. They are particularly well-suited for high-pressure systems and confined spaces because of their exceptional mechanical qualities and small size. They are also appropriate for seawater and wastewater treatment systems due to their resistance to oxidation and chlorides. In high-stress and corrosive environments, these fittings guarantee safe and maintenance-free operation.
