Heer Fittings, a trusted manufacturer and supplier based in Delhi, India, specializes in high-quality Monel Forged Fittings. Known for their exceptional corrosion resistance and durability, Monel fittings are ideal for harsh environments, including marine, chemical processing, and oil & gas industries. Heer Fittings ensures precision and reliability in every product, meeting the needs of demanding industrial applications. Our Monel Forged Fittings offer excellent performance under high pressure and temperature, providing long-lasting solutions for critical systems where performance and resistance are paramount.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500)
Monel Forged Fittings are primarily composed of nickel (63-70%) and copper (28-34%), with small amounts of iron, manganese, carbon, and silicon. This unique composition provides excellent resistance to corrosion, especially in seawater, acidic environments, and high-temperature applications. The mechanical properties of Monel include a tensile strength of up to 1034 MPa and a yield strength of around 483 MPa. Monel fittings also exhibit excellent resistance to stress corrosion cracking and pitting. These properties make Monel ideal for marine, chemical processing, and aerospace applications requiring high durability and resistance.
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
Heer Fittings is a leading supplier of Monel Forged Fittings in Delhi, India. We offer an extensive range of Monel Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
|---|---|---|---|---|---|---|---|
| Monel | 2.4360 | N04400 | NW 4400 | NA 13 | МНЖМц 28-2,5-1,5 | NU-30M | NiCu30Fe |
Choose Monel Forged Fittings from Heer Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Monel Forged Fittings offer several key advantages, including exceptional corrosion resistance, particularly in seawater and acidic environments. Their excellent resistance to pitting, crevice corrosion, and stress corrosion cracking makes them ideal for harsh conditions, such as marine and chemical processing applications. Monel fittings maintain their strength and integrity at elevated temperatures, offering superior durability in high-stress environments. They also possess excellent weldability and machinability, making installation and customization easier. With their long-lasting performance and ability to withstand extreme conditions, Monel Forged Fittings provide reliable solutions for critical industrial applications.
Yes, custom sizes for Monel Forged Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com
Monel Forged Fittings are widely used in industries requiring high strength and resistance to harsh environments. In marine applications, they are essential for seawater systems, pipelines, and pumps due to their resistance to corrosion and seawater. In chemical processing, Monel fittings are used in handling aggressive chemicals and high-temperature processes. They are also used in offshore oil and gas platforms, power generation plants, and aerospace industries, where durability, reliability, and corrosion resistance are critical. Monel Forged Fittings ensure long-lasting, high-performance solutions for demanding applications.
