Heer Fittings is a well-known supplier and exporter of Titanium Grade 2 Buttweld Fittings in Delhi, India. We emphasize quality, accuracy, and customer satisfaction above all, and provide high-performance pipe fittings that conform to rigorous global standards. Our buttweld fittings made of Titanium Grade 2 are recognized for their superior corrosion resistance, light-weight nature, and extended service life, thus suitable for critical industrial uses. We cater to a wide variety of industries, such as aerospace, chemical processing, marine, and medical. Heer Fittings promises competitive, economical solutions with guaranteed delivery within India and the global market.
| Specifications | ASTM B363 / ASME SB363 |
| Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size | ½”NB to 24″NB in Sch 10s, 40s, 80s, 160s, XXS. |
| Type | Seamless, ERW, Welded, Fabricated |
| Thickness | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS, Custom Thickness. |
| Pipe Fittings Type | Reducer (Concentric & Eccentric), CAP, Stubend (Long &Short), Nipple (Barrel), Bend (Long & Short), Elbow (180 Deg., 90 Deg. & 45 Deg.), Tee (Equal & Unequal) |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 2 | 3.7035 | R50400 |
Titanium Grade 2 Buttweld Fittings consist mostly of titanium (nearly 99%) with trace levels of iron, oxygen, carbon, nitrogen, and hydrogen. This unalloyed grade of titanium provides superior corrosion resistance, particularly in oxidizing and mildly reducing environments. Mechanically, it has tensile strength of approximately 344 MPa, yield strength of 275 MPa, and elongation of approximately 20%. Titanium Grade 2 offers moderate strength combined with good ductility and formability. It is resistant to structural deterioration over a broad spectrum of temperatures and is thus indicated where corrosion resistance and mechanical dependability are needed.
Heer Fittings is a leading supplier of Titanium Grade 2 Buttweld Fittings in Delhi, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Titanium Grade 2 Buttweld Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| ASME B16.9 ASTM B363 Grade 2 Fittings | Factory-Made Wrought Buttwelding Fittings | Long Radius Elbows, Long Radius Reducing Elbows, Long Radius Returns, Short Radius Elbows, Short Radius 180-deg Rerurns, 3D elbows, Straight Tees, Straight Crosses, Reducing Outlet Tees, Reducing Outlet Crosses, Lap Joint Stub Ends, Caps, Reducers |
| ASME B16.28 | Short Radius Elbows, Short Radius 180-deg Returns | |
| MSS SP43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications | Long Radius Elbows, Straight and Reducing-on-the-Outlet Tees, Lap Joint Stub ends, caps, long radius 180 Degree returns, concentric reducers, eccentric reducers |
| MSS SP75 | Long Radius Elbows, 3R elbows, straight tees, reducing outlet tees, caps, reducers |
| All Fittings | 90°and 45° Ells and Tees | Reducers and Lap Joint Stub | Caps | 180° Returns | Angularity Tol | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Nominal Pipe Plane Size (NPS) | Outside(1) Diameter at Bevel | Inside(1) Diameter at End | Wall(2) Thickness | Centre-to- End Dimension A,B,C,M | Overall Length L | Overall Length E | Centre-to- Centre Dimension O | Back-to- Face Dimension K | Alignment at Ends U | Nominal Pipe SIze | Off Angle Q | Off Angle P |
| 1/2 TO 2-1/2 | +1/16 | ±1/32 | Not less than 87-1/2% of Normal Thickness | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 12 to 4 | 1/32 | 1/16 |
| -1/32 | 5 to 8 | 1/16 | 1/8 | |||||||||
| 3 TO 3-1/2 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 10 to 12 | 3/32 | 3/16 | |
| 4 | ±1/16 | ±1/16 | ±1/16 | ±1/16 | ±1/8 | ±1/4 | ±1/4 | ±1/32 | 14 to 16 | 3/32 | 1/4 | |
| 5 TO 8 | +1/32 | ±1/16 | ±1/16 | ±1/16 | ±1/4 | ±1/4 | ±1/4 | ±1/32 | 18 to 24 | 1/8 | 3/8 | |
| -1/16 | ||||||||||||
| 10 TO 18 | +1/16 | ±1/8 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | All dimensions are in inches | |||
| -1/8 | ||||||||||||
| 20 TO 24 | +1/4 | ±3/32 | ±3/32 | ±3/32 | ±1/4 | ±3/8 | ±1/4 | ±1/16 | ||||
| -3/32 | ||||||||||||
Yes, custom sizes for Titanium Grade 2 Buttweld Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com.
Titanium Grade 2 Buttweld Fittings are found in various applications in industries where high corrosion resistance and biocompatibility are critical. They are used in the aerospace, marine, chemical processing, power generation, desalination plants, and medical device industry. In the chemical industry, they are used for the processing of chlorides, acids, and other corrosives. When they are used in marine environments, their corrosion resistance in seawater allows them to be long-lasting. In biomedical uses, their biocompatibility and non-toxicity make them a good fit for surgical devices and implants. Their strength-to-weight ratio and resistance to temperature also make them useful in aerospace components and heat exchanger components.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
