Heer Fittings, a well-respected manufacturer and supplier based in Delhi, India, proudly offers a top-notch selection of Incoloy 800, 800H, and 800HT Buttweld Fittings. These fittings are specifically crafted to handle the tough demands of high-temperature and corrosive environments. With a focus on precision engineering and adherence to international standards, they are perfect for industries like petrochemical, power generation, and heat treatment. Heer Fittings is committed to delivering consistent product quality, precise dimensions, and long-lasting durability through thorough testing and advanced fabrication methods, making them the go-to choice for clients who need high-performance and dependable solutions for their critical piping systems.
Specifications : ASTM B366 / ASME SB366
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″
Type : Seamless / Welded / Fabricated
Schedule : Sch 5 TO Sch XXS.
Thickness : 20 Swg., 18 Swg., 16 Swg., 14 Swg., 12 Swg., 10 Swg., & Sch. 10, Sch. 40, Sch. 80 etc
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
The Incoloy 800/800H/800HT Buttweld Fittings are primarily made up of nickel (30–35%), chromium (19–23%), and iron (at least 39.5%), along with small amounts of carbon, aluminum, and titanium to boost their strength and stability. These alloys boast impressive mechanical properties, with tensile strength between 500 and 600 MPa and yield strength ranging from 200 to 275 MPa, depending on the specific grade. They also provide outstanding resistance to oxidation, carburization, and high-temperature corrosion. The enhanced versions, 800H and 800HT, offer better creep and stress rupture strength, making them perfect for extended use in high-temperature, high-stress situations.
Heer Fittings is a leading supplier of Incoloy 800/ 800H/ 800HT Buttweld Fittings in Delhi, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy 800/ 800H/ 800HT Buttweld Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy 800, 800H, and 800HT buttweld fittings offer numerous advantages, including excellent high-temperature strength and superior resistance to oxidation and carburization. These alloys maintain stability and structural integrity in extreme environments, making them ideal for chemical processing, power plants, and heat exchangers. The addition of titanium in 800H and 800HT improves creep resistance and enhances long-term performance. Their outstanding weldability ensures easy fabrication, while high resistance to corrosion and stress cracking ensures longevity. These alloys provide durability, reducing maintenance and downtime in high-temperature industrial applications.
| Nominal PipeSize | Outside Diameter | 90° Elbows | 45° Elbows | 180° Returns | ||||
|---|---|---|---|---|---|---|---|---|
| (inches) | – | Long Radius | Short Radius | Long Radius | Long Radius | |||
| (mm) | (inches) | Center to Face (inches) | Center to Face (inches) | Center to Face (inches) | Radius (inches) | Center to Center (inches) | Back to face (inches) | |
| 1/2 | 21.3 | 0.840 | 1 1/2 | – | 5/8 | 2 | 1 7/8 | |
| 3/4 | 26.7 | 1.050 | 1 1/8 | 7/16 | 2 1/4 | 1 11/16 | ||
| 1 | 33.4 | 1.315 | 1 1/2 | 1 | 7/8 | 3 | 2 3/16 | |
| 1 1/4 | 42.2 | 1.660 | 1 7/8 | 1 1/4 | 1 | 3 3/4 | 2 3/4 | |
| 1 1/2 | 48.3 | 1.900 | 2 1/4 | 1 1/2 | 1 1/8 | 3 | 4 1/2 | 3 1/4 |
| 2 | 60.3 | 2.375 | 3 | 2 | 1 3/8 | 4 | 6 | 4 3/16 |
| 2 1/2 | 73.0 | 2.875 | 3 3/4 | 2 1/2 | 1 3/4 | 5 | 7 1/2 | 5 3/16 |
| 3 | 88.9 | 3.500 | 4 1/2 | 3 | 2 | 6 | 9 | 6 1/4 |
| 3 1/2 | 101.6 | 4.000 | 5 1/4 | 3 1/2 | 2 1/4 | 7 | 10 1/2 | 7 1/4 |
| 4 | 114.3 | 4.500 | 6 | 4 | 2 1/2 | 8 | 12 | 8 1/4 |
| 5 | 141.3 | 5.563 | 7 1/2 | 5 | 3 1/8 | 10 | 15 | 10 5/16 |
| 6 | 168.3 | 6.625 | 9 | 6 | 3 3/4 | 12 | 18 | 12 5/16 |
| 8 | 219.1 | 8.625 | 12 | 8 | 5 | 12 | 24 | 16 5/16 |
| 10 | 273.1 | 10.750 | 15 | 10 | 6 1/4 | 15 | 30 | 20 3/8 |
| 12 | 323.9 | 12.750 | 18 | 12 | 7 1/2 | 18 | 36 | 24 3/8 |
Yes, custom sizes for Incoloy 800/ 800H/ 800HT Buttweld Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com.
Incoloy 800/800H/800HT Buttweld Fittings are commonly found in high-temperature settings where strength, corrosion resistance, and stability are crucial. In the petrochemical sector, they are utilized in heat exchangers, ethylene furnace quench boilers, and hydrocarbon cracking systems. Power plants use them in superheaters and reheater tubing. Additionally, they are employed in industrial furnaces, heat-treating equipment, and pressure vessels due to their resistance to oxidation and thermal fatigue. Their ability to endure long-term exposure to high temperatures without compromising mechanical integrity makes them ideal for critical applications in demanding service conditions.
