Heer Fittings, located in Delhi, India, has built a solid reputation as a leading manufacturer and supplier of high-quality Incoloy Buttweld Fittings. They’re known for providing top-notch solutions tailored for high-performance piping systems. With a strong emphasis on precision, durability, and the ability to withstand extreme conditions, Heer Fittings offers a wide array of Incoloy Buttweld Fittings in various grades, including 800, 800H, 800HT, and 825. These fittings find their place in critical industries such as chemical processing, oil & gas, and power generation. Thanks to cutting-edge technology and rigorous quality control, Heer Fittings guarantees reliability and adherence to international standards in every product they produce.
| Specifications | : | ASTM B366 / ASME SB366 |
| Size | : | Seamless Butt Weld Fittings: 1/2″ – 10″, Welded Butt Weld Fittings: 1/2″ – 48″ |
| Standards | : | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Thickness | : | 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 |
| Type | : | Seamless / Welded / Fabricated |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| 800 | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60ᴬ | 0.15 – 0.60ᴬ |
| 825 | 0.05 max | 1.00 max | 0.5 max | 0.03 max | 1.50 – 3.00 | 22.00 min | 38.00 – 46.00 | 19.50 – 23.50 | 0.02 max | 0.06 – 1.20 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| 825 | 8.14 g/cm3 | 1400 °C (2550 °F) | Psi – 80,000 , MPa – 550 | Psi – 32,000 , MPa – 220 | 30 % |
Incoloy Buttweld Fittings are primarily made up of nickel (30–46%), chromium (19–23%), and iron, with varying amounts of molybdenum, copper, titanium, and aluminum depending on the specific grade. These fittings boast impressive mechanical properties, featuring tensile strength between 500 MPa and 700 MPa, and yield strength ranging from 200 MPa to 400 MPa. They also show remarkable resistance to oxidation, carburization, and stress corrosion cracking. The metallurgical stability of Incoloy ensures that these fittings perform reliably even under high temperatures and in highly corrosive environments, making them ideal for demanding industrial applications that require both strength and corrosion resistance.
Heer Fittings is a leading supplier of Incoloy Buttweld Pipe Fittings in Delhi, India. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy Pipe Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Incoloy Buttweld Fittings offer numerous advantages, making them a preferred choice across industries. Their excellent corrosion resistance ensures durability in harsh environments, including high temperatures and chemical exposure. These fittings provide superior mechanical strength, reducing the risk of failure under pressure. The seamless construction enhances flow efficiency and eliminates weak points, ensuring long-term reliability. Incoloy’s resistance to oxidation and stress-corrosion cracking adds to its versatility, making it ideal for marine, chemical, and power industries. Easy to weld and install, these fittings also ensure leak-proof and robust connections.
Yes, custom sizes for Incoloy Pipe Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com.
Incoloy Buttweld Fittings are widely utilized in industries that require exceptional resistance to corrosion, heat, and mechanical stress. In the chemical and petrochemical fields, they are commonly found in heat exchangers, reaction vessels, and pipelines that handle acidic and oxidizing agents. Power generation facilities use them in superheater and reheater tubing due to their ability to withstand high temperatures. Additionally, marine, nuclear, and pollution control systems benefit from their durability in harsh environments. These fittings play a crucial role in ensuring leak-proof, long-lasting connections in essential process systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
