Heer Fittings provides Inconel 600 Forged Fittings in Delhi, India, for use in high-strength applications with thermal stability and superior corrosion resistance. These forged fittings in the form of elbows, tees, couplings, unions, plugs, caps, bushings, etc., are manufactured to specifications such as ASTM B564, ASME B16.11, and MSS-SP-79/83/95. Inconel 600 (UNS N06600) is a nickel-chromium-iron superalloy that is suitable for use in high-temperature and corrosive environments, especially where oxidation resistance and chloride stress corrosion cracking resistance is critical.
| Standards | ASTM, ASME |
| Designation | B564, SB564 |
| Dimension Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Grade | Inconel 600 Forged Fittings. |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Types of Forged Fittings | Elbow, Tee, Union, Cross, Swage Nipples, Coupling, CAP, Plug, Bush. |
The composition of the alloy contains roughly 72% nickel, 14–17% chromium, and 6–10% iron with a balance of chemical resistance and mechanical strength. It yields a tensile strength of ~655 MPa, yield strength of ~240 MPa, and 30–45% elongation depending on the product form and heat treatment. Inconel 600 has mechanical integrity from cryogenic temperatures through 1093°C (2000°F) and is resistant to attack by acidic, alkaline, and oxidizing environments.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Heer Fittings is a leading supplier of Inconel 600 Forged Fittings in Delhi, India. We offer an extensive range of Inconel 600 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Choose Inconel 600 Forged Fittings from Heer Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Inconel 600 Forged Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com.
Inconel 600 Forged Fittings are extensively applied in chemical processing, power generation, marine systems, nuclear reactors, heat exchangers, and food processing equipment. The fittings are particularly appropriate for steam systems, furnace parts, and reactive chemical lines. Their long-term versatility due to thermal cycling and corrosive atmosphere exposure makes them perfect for long-term application in critical service environments. Inconel 600’s high weldability and non-magnetic property also make it dependable for sensitive and high-performance applications.
