Heer Fittings produces and provides top-quality Inconel 625 Forged Fittings in Delhi, India, for use under extreme pressure and temperature levels. Inconel 625 is an alloy of nickel-chromium-molybdenum-niobium with excellent strength, oxidation resistance, and weldability. Our forged fittings—like elbows, tees, bushings, couplings, and unions—are produced to ASTM B564 specifications and meet applications in critical usage in marine, aerospace, and chemical sectors. These fittings retain integrity under high corrosion and high-stress conditions. Heer Fittings provides precise dimensional tolerance and performance consistency for customers looking for dependable, long-term pipe connection solutions.
| Standards | ASTM, ASME |
| Designation | B564, SB564 |
| Dimension Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Grade | Inconel 625 Forged Fittings. |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Types of Forged Fittings | Elbow, Tee, Union, Cross, Swage Nipples, Coupling, CAP, Plug, Bush. |
Inconel 625 Forged Fittings consist of nickel (58%), chromium (20–23%), molybdenum (8–10%), and niobium (3.15–4.15%). The composition provides superior corrosion resistance, fatigue strength, and thermal stability. The fittings have tensile strength of ~827 MPa and show strength at a wide temperature range. They are weldable, non-magnetic, and are resistant to chloride stress-corrosion cracking. Produced according to ASTM B564 specifications, Inconel 625 forged fittings are highly effective in harsh environments that include acids, seawater, and salts. They are structurally designed against deformation in thermal as well as mechanical stress.
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
Heer Fittings is a leading supplier of Inconel 625 Forged Fittings in Delhi, India. We offer an extensive range of Inconel 625 Forged Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
Choose Inconel 625 Forged Fittings from Heer Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Inconel 625 Forged Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com
Inconel 625 Forged Fittings are applied in nuclear reactors, aerospace components, chemical process plants, and marine systems. They are well suited for high-temperature and high-pressure uses like piping systems in offshore oil rigs, exhaust pipes, and acid tank storage. They are resistant to oxidation, carburization, and crevice corrosion, making them find widespread use in heat exchangers, pressure vessels, and jet engine parts. These fittings are highly reliable in the long term and require little maintenance, thus proving vital in tough environments where mechanical integrity and chemical resistance are mandatory.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
