Heer Fittings is a prominent manufacturer and supplier of Carbon Steel P265GH Pipe Fittings in Delhi, India. The fittings are made from EN 10216-2 P265GH grade carbon steel that possesses superior weldability, pressure resistance, and thermal stability. Designed in a variety of configurations—elbows, tees, reducers, and caps—our pipe fittings find specific use in high-temperature and high-pressure applications like boilers, heat exchangers, and pressure vessels. By aligning to precision manufacturing and international standards, Heer Fittings provides reliable solutions for oil & gas, petrochemicals, and power generation industries.
| P265GH Carbon Steel Pipe Fittings size | P265GH Seamless Butt Weld Fittings : 1/2″ – 10″ P265GH Welded Butt Weld Fittings : 1/2″ – 48″ |
|---|---|
| CS P265GH Pipe Fittings Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1800, BS10 |
| P265GH Buttweld Fittings Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| P265GH Buttweld Pipe FittingsType | DN15-DN1200 |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fitting Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom ASTM A234 Gr P265GH Pipe Fitting |
| Size Range | ½” NB to 24″ NB in Sch 10s, 40s, 80s, 160s, XXS. (DN6~DN100) ASTM A234 P265GH Buttweld Fitting |
| EN 10253-1 / EN 10253-2 P265GH Buttweld Fittings Manufacturing process | Push, Press, Forge, Cast, etc. |
| P265GH Carbon Steel Buttweld Pipe Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| EN 10253-1 P265GH Pipe Fittings Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | CS 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| We provide Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
P265GH Pipe Fittings consist mainly of carbon (≤0.20%), manganese (0.90–1.60%), phosphorus (≤0.025%), and sulfur (≤0.015%). With a minimum yield point of 265 MPa and tensile strength ranging from 410–530 MPa, they are ideal for pressure-bearing applications. The fittings possess good machinability and ductility, making fabrication easier. Manufactured under EN 10216-2 and EN 10253-2 standards, they perform reliably under high temperature and pressure conditions, making them a staple in boiler and heat exchanger systems operating at temperatures up to 450°C.
| Element | % by mass | Element | % by mass |
| Carbon (C) | ≤0.20 | Silicon (Si) | ≤0.40 |
| Manganese (Mn) | 0.80 to 1.40 | Phosphorous (P) (maximum) | 0.025 |
| Sulphur (S) (maximum) | 0.015 | Aluminium (Al) | <=0.020 |
| Nitrogen (N) | <=0.012 | Chromium (Cr) | <=0.30 |
| Copper (Cu) | <=0.30 | Molybdenum (Mo) | <=0.08 |
| Niobium (Nb) | <=0.020 | Nickel (Ni) | <=0.30 |
| Titanium (Ti) (maximum) | 0.03 | Vanadium (Vi) | <=0.02 |
| Nominal thickness (millimeter): | to 100 | 100 – 150 | 150 – 250 |
| Rm – Tensile strength (MPa) (+N) | 410-530 | 400-530 | 390-530 |
Heer Fittings is a leading supplier of Carbon Steel P265GH Pipe Fittings in Delhi, India. We offer an extensive range of Carbon Steel P265GH Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Carbon Steel P265GH Pipe Fittings from Heer Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Yes, custom sizes for Carbon Steel P265GH Pipe Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com
| EU EN | USA – | Germany DIN,WNr | Japan JIS | France AFNOR | England BS | Italy UNI | Spain UNE | Sweden SS | Poland PN | Czechia CSN | Austria ONORM | Russia GOST | Inter ISO | ||||||||||||||||||||||||||||||
| P265GH Flange |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Nominal Pipe Size | Outside Diameter | Caps | Straight Tees | Straight Crosses | Stub Ends | |||
| inch | mm | inch | Length (inch) | Center to End (inch) | Center to End (inch) | Lap Diameter (inch) | Long Length (inch) | Short Length (inch) |
| 1/2 | 21.3 | 0.840 | 1 | 1 | – | 1 3/8 | 3 | 2 |
| 3/4 | 26.7 | 1.050 | 1 | 1 1/8 | – | 1 11/16 | 3 | 2 |
| 1 | 33.4 | 1.315 | 1 1/2 | 1 1/2 | 1 1/2 | 2 | 4 | 2 |
| 1 1/4 | 42.2 | 1.660 | 1 1/2 | 1 7/8 | 1 7/8 | 2 1/2 | 4 | 2 |
| 1 1/2 | 48.3 | 1.900 | 1 1/2 | 2 1/4 | 2 1/4 | 2 7/8 | 4 | 2 |
| 2 | 60.3 | 2.375 | 1 1/2 | 2 1/2 | 2 1/2 | 3 5/8 | 6 | 2 1/2 |
| 2 1/2 | 73.0 | 2.875 | 1 1/2 | 3 | 3 | 4 1/8 | 6 | 2 1/2 |
| 3 | 88.9 | 3.500 | 2 | 3 3/8 | 3 3/8 | 5 | 6 | 2 1/2 |
| 3 1/2 | 101.6 | 4.000 | 2 1/2 | 3 3/4 | 3 3/4 | 5 1/2 | 6 | 3 |
| 4 | 114.3 | 4.500 | 2 1/2 | 4 1/8 | 4 1/8 | 6 3/16 | 6 | 3 |
| 5 | 141.3 | 5.563 | 3 | 4 7/8 | 4 7/8 | 7 5/16 | 8 | 3 |
| 6 | 168.3 | 6.625 | 3 1/2 | 5 5/8 | 5 5/8 | 8 1/2 | 8 | 3 1/2 |
| 8 | 219.1 | 8.625 | 4 | 7 | 7 | 10 5/8 | 8 | 4 |
| 10 | 273.1 | 10.750 | 5 | 8 1/2 | 8 1/2 | 12 3/4 | 10 | 5 |
| 12 | 323.9 | 12.750 | 6 | 10 | 10 | 15 | 10 | 6 |
| DN | Schedule 10S | Schedule 40S | Schedule 80S | ||||||
| 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | 900 Elbow | 450 Elbow | Equal tee | |
| 8 | 0.02 | 0.01 | 0.03 | 0.03 | 0.02 | 0.06 | 0.04 | 0.03 | 0.07 |
| 10 | 0.03 | 0.02 | 0.05 | 0.03 | 0.02 | 0.03 | 0.06 | 0.04 | 0.09 |
| 15 | 0.06 | 0.03 | 0.09 | 0.08 | 0.04 | 0.10 | 0.10 | 0.05 | 0.14 |
| 20 | 0.07 | 0.03 | 0.13 | 0.08 | 0.04 | 0.17 | 0.11 | 0.05 | 0.20 |
| 25 | 0.14 | 0.08 | 0.28 | 0.15 | 0.11 | 0.29 | 0.22 | 0.14 | 0.38 |
| 32 | 0.23 | 0.11 | 0.49 | 0.26 | 0.17 | 0.59 | 0.40 | 0.23 | 0.68 |
| 40 | 0.30 | 0.17 | 0.68 | 0.40 | 0.23 | 0.86 | 0.51 | 0.29 | 1.02 |
| 50 | 0.50 | 0.25 | 0.85 | 0.70 | 0.4 | 1.28 | 0.91 | 0.59 | 1.59 |
| 65 | 0.85 | 0.48 | 1.41 | 1.40 | 0.77 | 2.19 | 1.81 | 0.99 | 3.13 |
| 80 | 1.25 | 0.63 | 1.77 | 2.20 | 1.08 | 3.31 | 2.97 | 1.50 | 4.45 |
| 90 | 1.70 | 0.75 | 2.67 | 2.83 | 1.42 | 4.08 | 4.00 | 2.00 | 5.44 |
| 100 | 2.10 | 1.08 | 3.46 | 4.47 | 2.09 | 5.27 | 6.18 | 2.81 | 7.71 |
| 150 | 5.45 | 2.72 | 8.07 | 10.89 | 5.44 | 10.99 | 16.32 | 8.16 | 13.61 |
| 200 | 10.20 | 5.33 | 15.65 | 21.54 | 10.77 | 20.91 | 33.11 | 16.56 | 28.12 |
| 250 | 18.15 | 9.75 | 26.46 | 38.56 | 19.27 | 35.38 | 51.71 | 25.86 | 49.90 |
| 300 | 25.80 | 13.62 | 39.46 | 59.42 | 29.71 | 62.14 | 79.38 | 39.69 | 83.91 |
Carbon Steel P265GH Pipe Fittings are widely used in thermal power plants, oil refineries, and chemical processing systems. Their strength and thermal resistance qualify them for use in steam pipelines, boiler tubing, pressure vessels, and industrial heat exchangers. They are also found in HVAC units and water treatment facilities where high performance under pressure is needed. Their formability and weldability make it easy to integrate into piping networks. Cost-effective and durable, P265GH fittings prove an excellent choice for critical as well as non-critical applications in industries requiring heat and pressure proofing.
