Heer Fittings, based in Delhi, India, has made a name for itself as a leading manufacturer and supplier of Low Temperature A420 WPL6 Pipe Fittings. These fittings are essential for industries that need robust and impact-resistant piping solutions in sub-zero conditions. With a commitment to top-notch quality, precise fabrication, and strict adherence to international standards, Heer Fittings delivers A420 WPL6 fittings that stand out for their performance and reliability. Engineered specifically for critical applications in cryogenic services and low-temperature pressure systems, these fittings have earned the trust of sectors like oil & gas, petrochemicals, and power generation. Heer Fittings has established a solid reputation for providing consistent, cost-effective solutions that thrive in extreme service conditions.
Specification : ASTM A420 / ASME SA420
Dimension Standard : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43
Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Type : Seamless / Welded / Fabricated
The Low Temperature A420 WPL6 Pipe Fittings are crafted from carbon steel, carefully blended with controlled amounts of manganese, phosphorus, sulfur, and silicon. To boost their toughness and performance in low temperatures, these fittings undergo normalization and tempering. They typically boast a tensile strength between 485 and 655 MPa, with a minimum yield strength of 240 MPa. Designed to function effectively at temperatures as low as -46°C, WPL6 fittings are known for their excellent ductility, weldability, and impact resistance. Their well-balanced chemical composition and mechanical strength make them perfect for high-pressure and low-temperature applications where safety and reliability are paramount.
| Grade | C | Mn | Si | S | P | Cr | Mo |
| A420 WPL6 | 0.3 | 0.60-1.35 | 0.15-0.30 | 0.04 | 0.035 | 0.3 | 0.12 |
| Grade | Tensile Strength (Mpa) | Yield Strength (Mpa) |
| A420 WPL6 | 60-85[415-585] | 35[240] |
Heer Fittings is a leading supplier of Low Temperature A420 WPL6 Pipe Fittings in Delhi, India. We offer an extensive range of Low Temperature A420 WPL6 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Low Temperature A420 WPL6 Pipe Fittings from Heer Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Low Temperature A420 WPL6 pipe fittings offer several advantages, including excellent toughness and strength at low temperatures, making them ideal for extreme environments. They provide outstanding resistance to brittle fracture, ensuring safety and reliability in cold conditions. These fittings also maintain high tensile strength and durability under stress, reducing the risk of failure in critical applications. Their corrosion resistance ensures a long service life, making them a cost-effective choice. Widely used in industries like oil and gas, petrochemical, and power generation, A420 WPL6 fittings guarantee dependable performance in harsh environments.
Yes, custom sizes for Low Temperature A420 WPL6 Pipe Fittings are available at Heer Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@heerfittings.com
| Material | Fttg | Valves | Flg | Pipes | Bolts and Nuts |
|---|---|---|---|---|---|
| Low Temperature Carbon Steel Alloy Low-Temp | A420 Gr WPL6 | A352 Gr LCB | A350 Gr LF2 | A333 Gr 6 | A320 Gr L7 A194 Gr 7 |
| A420 Gr WPL3 | A352 Gr LC3 | A350 Gr LF3 | A333 Gr 3 |
| Nom. Pipe Size | ASTM A420 Carbon Steel 90° Elbows | ASTM A420 Carbon Steel 45° Elbows | ASTM A420 Carbon Steel 180° Return Long Radius | |||||||||||
| Long Radius | Short Radius | 3R | Long Radius | 3R | STD | XS | ||||||||
| STD | XS | SCH. 160 | XXS | STD | XS | STD | XS | STD | XS | STD | XS | |||
| ½ | .18 | .25 | .09 | .19 | .35 | |||||||||
| ¾ | .19 | .25 | .09 | .19 | .40 | .65 | ||||||||
| 1 | .40 | .50 | .60 | .75 | .25 | 0.25 | .31 | .75 | 1.00 | |||||
| 1¼ | .60 | .90 | 1.00 | 1.38 | .4 | 0.38 | .50 | 1.25 | 1.75 | |||||
| 1½ | .90 | 1.15 | 1.80 | 1.50 | .56 | .75 | .40 | .69 | 1.88 | 2.39 | ||||
| 2 | 1.60 | 2.20 | 3.25 | 3.50 | 1.00 | 1.50 | 3.00 | 4.00 | .81 | 1.19 | 1.5 | 2.1 | 3.23 | 4.40 |
| 2½ | 3.25 | 4.00 | 5.13 | 7.00 | 2.13 | 2.80 | 6.00 | 8.00 | 1.75 | 2.13 | 3.00 | 4.00 | 6.50 | 8.00 |
| 3 | 5.00 | 6.50 | 8.50 | 11.0 | 3.00 | 4.25 | 10.0 | 13.0 | 2.63 | 3.50 | 5.00 | 7.00 | 10.25 | 13.00 |
| 3½ | 6.75 | 8.35 | 16.0 | 4.50 | 6.00 | 13.0 | 18.0 | 3.50 | 4.50 | 7.00 | 9.00 | 13.00 | 16.75 | |
| 4 | 9.00 | 13.5 | 18.0 | 20.0 | 6.25 | 8.50 | 18.0 | 25.0 | 4.50 | 6.10 | 9.00 | 13.0 | 18.5 | 25.0 |
| 5 | 15.0 | 22.0 | 32.0 | 36.0 | 9.60 | 14.0 | 29.0 | 43.0 | 7.50 | 10.7 | 15.0 | 22.0 | 30.0 | 44.0 |
| 6 | 24.5 | 35.0 | 57.0 | 65.0 | 18.0 | 23.0 | 45.0 | 70.0 | 12.0 | 17.5 | 23.0 | 35.0 | 50.0 | 70.0 |
| 8 | 50.0 | 71.0 | 120 | 118 | 34.0 | 47.5 | 90.0 | 140 | 23.0 | 35.0 | 45.0 | 70.0 | 95.0 | 142 |
| 10 | 88.0 | 107 | 260 | 58.0 | 70.0 | 159 | 218 | 43.0 | 53.0 | 80.0 | 109 | 117 | 215 | |
| 12 | 125 | 160 | 450 | 80.0 | 104 | 233 | 310 | 62.0 | 84.0 | 117 | 155 | 230 | 320 | |
| 14 | 160 | 205 | 572 | 105 | 140 | 298 | 400 | 80.0 | 100 | 149 | 200 | 325 | 400 | |
| 16 | 206 | 276 | 132 | 174 | 390 | 520 | 100 | 135 | 195 | 260 | 412 | 550 | ||
| 18 | 260 | 340 | 167 | 219 | 495 | 660 | 126 | 167 | 248 | 330 | 510 | 690 | ||
| 20 | 320 | 420 | 210 | 275 | 610 | 810 | 160 | 206 | 305 | 405 | 640 | 830 | ||
| 22 | 394 | 520 | 735 | 980 | 197 | 260 | 368 | 490 | 787 | 1040 | ||||
| 24 | 460 | 600 | 298 | 392 | 875 | 1170 | 238 | 300 | 438 | 585 | 890 | 1200 | ||
| 26 | 550 | 729 | 1030 | 1370 | 275 | 365 | 515 | 685 | ||||||
| 30 | 734 | 975 | 1370 | 1830 | 367 | 488 | 685 | 915 | ||||||
| 36 | 1062 | 1412 | 1970 | 2630 | 531 | 706 | 985 | 1315 | ||||||
These Low Temperature A420 WPL6 Pipe Fittings find extensive use in scenarios that demand exceptional toughness in sub-zero temperatures. In the oil and gas sector, they are frequently installed in LNG plants, offshore platforms, and cryogenic pipelines. Chemical processing and petrochemical facilities utilize them in low-temperature fluid systems to manage volatile or reactive substances. Power generation units, particularly those operating in colder climates, depend on these fittings for steam, condensate, and fuel lines. Their reliability in extreme cold conditions ensures operational integrity and safety in high-risk, low-temperature environments.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
