Heer Fittings, based in Delhi, India, stands out as a leading manufacturer and supplier of Stainless Steel 304L Pipe Fittings, delivering dependable and high-performance solutions for a variety of industries. With a strong commitment to quality, precision, and customer satisfaction, Heer Fittings offers a wide selection of elbows, tees, reducers, and caps made from SS 304L. These fittings are produced under stringent quality standards like ASTM A403, ensuring they provide long-lasting performance and resist corrosion. Heer Fittings has built a solid reputation for supplying durable and cost-effective pipe fittings in both domestic and international markets.
| Specifications | : | ASTM A182 ASME SA 182 |
| Tube Size | : | 1/16”OD to 2”OD, 2mm OD to 50mm OD |
| Thread | : | NPT, BSP, BSPT, UNF, ISO, SAE etc. |
| Pressure Rating | : | 6000PSI for Stainless Steel, 300/1000/3000PSI for Brass |
Stainless Steel 304L Pipe Fittings are made up of chromium (18–20%), nickel (8–12%), and have a low carbon content (maximum 0.03%), which improves weldability and reduces carbide precipitation. This unique composition gives them excellent corrosion resistance in various environments, including oxidizing and mildly reducing conditions. Their mechanical properties include a tensile strength of around 485 MPa, yield strength of 170 MPa, and an elongation of 35–40%. These characteristics make 304L fittings perfect for applications that demand durability, formability, and resistance to intergranular corrosion during welding.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 304L | 0.035 max | 2 max | 1.0 max | 0.045 max | 0.030 max | 18 – 20 | – | 8 – 13 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Heer Fittings one of the largest suppliers of Stainless Steel 304L Pipe Fittings in Delhi, India. We specialize in providing a wide range of high-quality, durable fittings for various industrial applications. Our inventory includes elbows, tees, reducers, couplings, and other essential fittings designed to offer exceptional corrosion resistance and strength. Stainless Steel 304L is known for its cost-effectiveness and excellent mechanical properties, making it ideal for industries such as construction, chemical processing, and food processing. With a commitment to customer satisfaction, timely delivery, and competitive pricing, we are the trusted choice for Stainless Steel 304L Pipe Fittings in the India.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless Steel 304L Pipe Fittings from Heer Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| Nominal Pipe Size | All Fittings | All Fittings | All Fittings | Elbows/ Tees | 180° Return Bends | 180° Return Bends | 180 Deg Return Bends | Reducers | Caps |
|---|---|---|---|---|---|---|---|---|---|
| NPS | O.D. at Bevel (1), (2) | I.D. at End (1), (3), (4) | Wall Thickness (3) | Centre-to-End Dimension A,B,C,M | Centre-to-Centre O | Back-to-Face K | Alignment of Ends U | Overall Length H | Overall Length E |
| ½ to 2½ | 0.06 -0.03 | 0.03 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 3 to 3 ½ | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 4 | 0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.12 |
| 5 to 8 | 0.09 -0.06 | 0.06 | Not less than 87.5% of nominal thickness | 0.06 | 0.25 | 0.25 | 0.03 | 0.06 | 0.25 |
| 10 to 18 | 0.16 -0.12 | 0.12 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 20 to 24 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.09 | 0.38 | 0.25 | 0.06 | 0.09 | 0.25 |
| 26 to 30 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.12 | … | … | … | 0.19 | 0.38 |
| 32 to 48 | 0.25 -0.19 | 0.19 | Not less than 87.5% of nominal thickness | 0.19 | … | … | … | 0.19 | 0.38 |
| Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
| BS | En | No | Name | ||||
| 304L | S30403 | 304S11 | 58E | 1.4301 | X5CrNi18-10 | 2332 | SUS 304L |
Stainless steel 304L pipe fittings provide excellent corrosion resistance, especially in sensitive corrosion and oxidizing environments. Their low carbon content reduces carbide precipitation during welding, resulting in better weldability and reduced risk of intergranular corrosion. These fittings are durable, versatile and maintain high strength at even at elevated temperatures. It is easy to make and wash, making it suitable for hygiene-critical applications such as food processing and pharmaceuticals. Due to their excellent durability they perform well in both cryogenic and high temperature environments making them a reliable choice for a variety of industrial and commercial applications.
Yes, custom sizes are available for Stainless Steel 304L Pipe Fittings to meet specific requirements. We offer tailored solutions to ensure precise fit and performance for various applications. For more information, please contact us at sales@heerfittings.com.
You’ll find Stainless Steel 304L Pipe Fittings used in a wide range of industries, including food processing, pharmaceuticals, dairy, chemical processing, and water treatment. Thanks to their low carbon content and corrosion resistance, they are especially well-suited for welded applications and systems that deal with corrosive media. These fittings are commonly found in piping systems where hygiene, cleanliness, and longevity are crucial. Their rust resistance, ease of fabrication, and compatibility with sanitary environments make them ideal for both commercial and industrial fluid transport systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
